TP-Link Archer C3200 User Manual

Archer C3200 AC3200 Wireless Tri-Band Gigabit Router
Chapter 3. Log into Your Router
1. If the TCP/IP Protocol on your computer is set to the static (fixed) IP address, you need to
change it to obtain an IP address automatically.
2. Enter http://tplinkwifi.net or http://192.168.0.1
in the address bar of a web browser.
3. Use admin for both username and password, and click Login.
)
)
Note:
If the above screen does not pop up, it means that your Web-browser has been set to a proxy.
Go to Tools menu>Internet Options>Connections>LAN Settings, in the screen that
appears, cancel the Using Proxy checkbox, and click OK to finish it.
4. Create a new username and password for subsequent login.
- 9 -

TP-Link Archer C3200 Specifications

General

DSL WAN	-
Ethernet WAN	Yes
SIM card slot	No
Firewall security	Domain Filter, IP Address Binding, MAC Address Binding
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
VPN support	PPTP, L2TP, IPSec
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	5GHz: 11a 6Mbps: -94dBm 11a 54Mbps: -76dBm 11ac HT20: -68dBm 11ac HT40: -64dBm 11ac HT80: -60dBm 2.4GHz 11g 54M: -77dBm 11n HT20: -73dBm 11n HT40: -71dBm
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Tri-band (2.4 GHz / 5 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
Number of WLAN connections (max)	4
WLAN data transfer rate (third band)	600 Mbit/s
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Link, Power, WLAN
Housing material	Plastic
USB 2.0 ports quantity	1
Output current	5 A
Output voltage	12 V
Power source type	AC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Certification	CE, FCC, RoHS
Antennas quantity	6
Cables included	LAN (RJ-45)
Package type	Box

Weight and Dimensions

Width	200 mm
Height	39 mm
