Archer C3200 AC3200 Wireless Tri-Band Gigabit Router
The VPN (Virtual Private Network) technology is developed and used to establish the private
network through the public network, which can provides a secure communication to a remote
computer or remote network, and guarantee a secured data exchange.
I want to:
Establish an IPSec VPN tunnel between two units which support IPSec protocol.
For example, I am a field staff and want to set up a VPN connection with
company headquarters. Here Site A refers to my local network. And Site B refers
to the remote network which I want to connect.
The following diagram is a typical VPN topology.
How can I
do that?
1. Make sure the topology you want to build and record site A (local network)
and site B (remote network)’s LAN IP and WAN IP.
2. Configuration on site A (local network).
1) Visit http://tplinkwifi.net
, and log in with the password you set for the
router.
2) Click Advanced > Network > IPSec VPN to open the configuration
page.
- 81 -
