TP-Link EC120-F5 - Configure the Bandwidth Control; Create Controlling Rules

26
Chapter 6 Bandwidth Control
6. 1. Configure the Bandwidth Control
Bandwidth Control allows you to configure the Upstream Bandwidth and Downstream
Bandwidth of the network, follow the steps below to configure the bandwidth.
1. Visit http://tplinkwifi.net, and log in with the password you set for the router.
2. Go to Advanced > Bandwidth Control, and enable Bandwidth Control.
3. Input the total upload and download speed through the WAN port in the Total
Upstream Bandwidth and Total Downstream Bandwidth field. For optimal bandwidth
control, please consult your ISP for the total allowed bandwidth for upstream and
downstream.
4. Click Save to make the settings effective.
6. 2. Create Controlling Rules
To add a new rule for the Bandwidth Control:
1. Click Add.
