Assignment of the status byte
Bit
Definition
25
Ready status
0
Measuring system not ready-to-operate
1
Measuring system ready-to-operate
26
Operating mode
0
Commissioning mode
1
Normal mode
27
Software limit switches
0
process-actual value  lower limit switch or
process-actual value  upper limit switch
1
process-actual value < lower limit switch or
process-actual value > upper limit switch
28
Counting direction
(at the moment)
0
Counting direction cw (with view on the shaft)
1
Counting direction ccw (with view on the shaft)
29
Teach-In,
takeover drive distance
0
not supported!
1
not supported!
30
Start Teach-In
0
not supported!
1
not supported!
31
Adjustment
acknowledgement
0
No adjustment requested
1
Requested adjustment was executed
Assignment of the control byte
Bit
Definition
25
no meaning
26
no meaning
27
no meaning
28
Change counting direction
0
Keep counting direction
1
Invert present counting direction
29
Takeover Teach-In
0
not supported!
1
not supported!
30
Start Teach-In
0
not supported!
1
not supported!
31
Adjustment request
0
No adjustment requested
1
Adjust measuring system to the preset value
