TR-Electronic LMRB-48 - Axial Sealing; Sealing Options

Installation in hydraulic cylinders
 TR-Electronic GmbH 2007, All Rights Reserved Printed in the Federal Republic of Germany
Page 44 of 51 TR-ELA-BA-DGB-0004 v16 03/17/2021
5.1 Sealing options
5.1.1 Axial sealing
LA-42
not specified dimensions see customized drawing!
Steel Tube
O-Ring / 23.47x2.62
SW46
44.5
45°
LA-65-H
not specified dimensions see customized drawing!
O-Ring / 23.47x2.62
Steel Tube
LA-66
not specified dimensions see customized drawing!
Borehole 5
4 deep (8x45°)

Steel Tube
