3.2 Cable definition
Signal
Line (e.g. TR Art.-No.: 64-200-021)
Analog + / Analog -
min. 0,25 mm
2
, twisted in pairs and shielded
Set-Input
Supply voltage
min. 0,5 mm
2
, twisted in pairs and shielded
3.3 Connection – Notes
Mainly, the electrical characteristics are defined by the variable connection technique.
The connection can be made only in connection with the device specific pin
assignment!
At the delivery of the measuring system one device specific pin assignment in printed
form is enclosed and it can be downloaded afterwards from the page
„www.tr-electronic.com/service/downloads/pin-assignments.html”. The number of the
pin assignment is noted on the nameplate of the measuring system.
For multiple redundant measuring systems, the connection must be carried out
separately for each interface unit.
3.4 Status LEDs at multiple redundant measuring systems
Multiple redundant measuring systems have a separate status LED for each interface
unit.
LED Status
Meaning
off
no supply voltage
on, green
Interface unit is ready for operation and error free
on, red
Error occurred at the interface unit
