4.3 Measuring Range
The measuring range with start and end point is either factory-programmed or,
depending on the measuring system version and the connection, it can be set by the
customer. See chapters 4.3.1 or 4.3.2 and the device-specific pin assignment.
For multiple redundant measuring systems, the measuring range for each scanning
unit must be seen separately.
Figure 1: Measurement of the analog signal with the ex-works setting.
Figure 2: Examples of the setting of a rising and falling analog signal.
