TR-Electronic LMRS-34 - Index 0 X0045: Filter; Index 0 X0046: Position; Index 0 X0047: Velocity Unit

Parameterization
 TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany
Page 44 of 52 TR-ELA-BA-DGB-0026-04 01/26/2023
7.2.4 Index 0x0045: Filter
With the parameter Filter the output position value can be averaged and results in
a small output jitter.
Index
Subindex
Name
Length
Type
Access
0x0045
0
Filter
8 Bit
UIntegerT
r/w
Value
Assignment
Description
Default
0x0001
filter off
no averaging
X
0x0002
filter level 2
averaging of 2 values
0x0004
filter level 4
averaging of 4 values
0x0008
filter level 8
averaging of 8 values
7.2.5 Index 0x0046: Position
Determination of the position value to which the measuring system is adjusted if the
“Set position function” is executed, see page 46.
Index
Subindex
Name
Length
Type
Access
0x0046
0
Position
32 Bit
IntegerT
r/w
Byte
x+0
x+1
x+2
x+3
Bit
31 – 24
23 – 16
15 – 8
7 – 0
Data
2
31
– 2
24
2
23
– 2
16
2
15
– 2
8
2
7
– 2
0
Position value (two's complement)
Lower limit
-2 147 483 648 (0x80000000)
Upper limit
programmed total measuring length in steps,
within of +2 147 483 647 (0x7FFFFFFF)
Default
0
7.2.6 Index 0x0047: Velocity unit
The parameter Velocity unit defines the resolution for the velocity output.
Index
Subindex
Name
Length
Type
Access
0x0047
0
Velocity unit
16 Bit
UIntegerT
r/w
Value
Assignment
Description
Default
0x0001
velocity in 0.1mm/s
output in 0.1 mm/s
X
0x000A
velocity in mm/s
output in 1.0 mm/s
