9 Troubleshooting and diagnosis options
9.1 Error count (Index 0x0020)
The parameter Error Count provides information on errors occurred (Events) since
power-on.
Index
Subindex
Name
Length
Type
Access
0x0020
0
Error Count
16 Bit
UIntegerT
ro
9.2 Device status (Index 0x0024)
The parameter Device Status contains the current device status and can be read
by any PLC program or corresponding IO-Link tools.
In case of an error by means of the parameter Detailed device status (Index
0x0025) the cause of the error is indicated in detail.
Index
Subindex
Name
Length
Type
Access
0x0024
0
Device Status
8 Bit
UIntegerT
ro
Parameter value
Description
0x00
No failure,
device is operating properly
0x01
Not supported
0x02
Out-of-Specification,
process data valid -> WARNING - EVENT
0x03
Not supported
0x04
Failure occurred,
process data invalid -> ERROR - EVENT
0x05...0xFF
Reserved
