ã
1999 Trace Engineering
RC7 & RC7GS Remote Controls
3.0 OPERATION
4. AC Output Voltage
This meter displays the actual inverter ac output voltage measured at the
ac output. When in the charger mode, the meter will read 0 VAC. Search mode
is indicated by < 40 VAC appearing in the display.
Figure 56
Meter Mode Display–AC Output Voltage
Inverter Output:
0 VAC
5. AC Input Amps
This meter displays the actual ac current (in amps) flowing through the
inverters AC INPUT HOT 1 terminal.
AC Input:
1 Amps AC
Figure 57
Meter Mode Display–AC Input Amps
6. Battery Temperature
This meter displays the external temperature of the battery bank when
equipped with a Battery Temperature Sensor (BTS). The scale is divided into
counts, which do not directly correspond to the Fahrenheit or Celsius
temperature scale. A higher reading indicates a lower temperature. This meter is
useful for service technicians.
Battery Temp:
000 Counts
Figure 58
Meter Mode Display–Battery Temperature
29
