ã
1999 Trace Engineering
RC7 & RC7GS Remote Controls
3.0 OPERATION
30
7. Transformer Temperature
This meter displays the internal temperature of the inverter/chargers
transformer. The scale is divided into counts, which do not directly correspond to
the Fahrenheit or Celsius temperature scale. A higher reading indicates a lower
temperature. This meter is useful for service technicians.
Xformer Temp:
000 Counts
Figure 59
Meter Mode Display–Transformer Temperature
8. FET Temperature
This meter displays the relative temperature of the Field Effect Transistors.
The scale is divided into counts, which do not directly correspond to the
Fahrenheit or Celsius temperature scale. A higher reading indicates a lower
temperature. This meter is useful for service technicians.
FET Temp:
000 Counts
Figure 60
Meter Mode Display–FET Temperature
9. Estimated Battery Capacity
This meter displays the estimated battery amp-hour capacity based upon
the average amp-hours used and the rate and duration of the charging cycles.
Multiply the reading by eight to arrive at the approximate battery capacity. This is
only an approximation and becomes more accurate as the number of charge/
discharge cycles increases (approximately 1520 charge/discharge cycles).
NOTE: If battery power is removed from the inverter, the calculation process
restarts. 1520 charge/discharge cycles must complete to reach accurate battery
capacity.
Est. Bat. Cap:
00 Amp-hrs(x8)
Figure 61
Meter Mode Display–Estimated Battery Capacity
