Trane RTHD

RTHD-SVX01D-EN 101
TechView
Table 21 Status View Items
Tab Text Units
Chiller Active Chilled Water Setpoint / Source Temperature
Active Current Limit Setpoint / Source Percent RLA
Active Base Loading Setpoint / Source Percent
Active Ice Termination Setpoint / Source Temperature
Evaporator Entering Water Temperature Temperature
Evaporator Leaving Water Temperature Temperature
Chilled Water Pump Relay (on/off)
Evaporator Water Flow Switch Status (Flow/NoFlow)
Condenser Entering Water Temperature Temperature
Condenser Leaving Water Temperature Temperature
Condenser Water Pump Relay (on/off)
Condenser Water Flow Switch Status (Flow/NoFlow)
Outdoor Air Temperature Temperature
Refrigerant Monitor Ppm
Circuit Evaporator Saturated Refrigerant
Temperature
Temperature
Evaporator Refrigerant Pressure Pressure
Evaporator Approach Temperature Diff.
Temperature
Evaporator Liquid Level Level
Condenser Saturated Refrigerant
Temperature
Temperature
Condenser Refrigerant Pressure Pressure
Condenser Approach Temperature Diff.
Temperature
Discharge Superheat Diff.
Temperature
Expansion Valve Position Percent
Expansion Valve Position Steps Steps
HPC Switch Status (Closed/
Tripped)
