Trane RTHD Installation Operation & Maintenance

102 RTHD-SVX01D-EN
TechView
Compressor Compressor Running Status (On/Off)
Compressor Starts Integer
Compressor Run Time Hrs:mins
Compressor Refrigerant Discharge Temp Temperature
Oil Return Gas Fill Solenoid Valve Status (Open/Closed)
Oil Return Gas Drain Solenoid Valve Status (Open/Closed)
Oil Loss Level Sensor (Dry/Wet)
Oil Pressure Pressure
Oil Pressure Ratio Pressure Ratio-
Psid/Psid or
Kpa/Kpa
System Refrigerant Differential Pressure Diff Pressure
Restart Inhibit Time Remaining Min:sec
Line Current L1, L2, L3 Percent RLA
Line Current L1, L2, L3 amps
Phase Voltage AB BC CA volts
Average Line Current Percent RLA
Average Line Current amps
Maximum Line Current Percent RLA
Average Phase Voltage volts
Condenser
Head Pressure
(optional)
Flow Commanded Percent
Output Voltage Commanded Voltage
Modes Chiller Top Level Mode Text
Chiller Sub Modes Text
Chiller Mode at Time of Last Diagnostic Text
Chiller Sub Modes at Time of Last
Diagnostic
Text
Table 21 Status View Items
Tab Text Units

Trane RTHD Specifications

General

Type	Water-Cooled Chiller
Refrigerant	R-134a
Compressor Type	Helical Rotary (Screw)
Voltage Options	200, 230, 380, 460, 575
Capacity Range	200 - 4000 tons (703 kW - 14, 060 kW)
