Trane RTHD

RTHD-SVX01D-EN 105
TechView
Table 22 Setpoint View Items
Tab Setpoint
(Min, Max), Default Units
Chiller Front Panel Chilled Water Setpoint (-17.78, 18.33), 6.67 °C Temperature
Front Panel Current Limit Setpoint (40, 100), 100 %RLA Percent RLA
Front Panel Ice Building Command On/auto Enum
Front Panel Ice Termination Setpoint (-6.67, 0.0), -2.78 °C Temperature
Ice To Normal Cooling Timer (0-10), 5 min Minutes
Front Panel Base Loading Command On/auto Enum
Front Panel Base Loading Setpoint (40-100),50 Percent
Differential to Start Setpoint (0.55, 5.55), 2.78 °C Diff Temperature
Differential to Stop Setpoint (0.55, 5.55), 2.78 °C Diff Temperature
Setpoint Source (BAS/Ext/FP, Ext Front
Panel, Front Panel),
BAS/Ext/FP
Enum
Power Up Start Delay (0, 600), 0 sec Seconds
Evaporator Water Pump Off Delay (0, 30), 1 min Minutes
Condenser Pump Prestart Time (0, 30), 0 min Minutes
Evaporator Design Delta Temperature (2.22, 16.7), 5.56 °C Diff Temperature
Evaporator Leaving Water Temperature
Cutout
(-18.33, 2.22), 2.22 °C
"Warning: Adequate
Antifreeze Required
<1.83°C
Temperature
Low Refrigerant Temp Cutout (-20.55, 2.22), -1.89 °C
"Warning: Adequate
Antifreeze Required <-
1.94°C
Temperature
Condenser High Refrigerant Pressure Setting (80, 120), 90 %HPC Percent HPC
High Evap Water Temp Cutout (26.6 , 65.5°C), 40.5°C Temperature
Restart Inhibit Free Starts (1, 5), 3 Starts
Restart Inhibit Start to Start Time (5, 30), 10 min Minutes
Restart Inhibit Diagnostic (Enable Disable),
Enable
Enum
Local Atmospheric Pressure (68.95, 110.32), 101.35
kPa (absolute)
Pressure
Head Relief Relay Filter Time (1-60),10
Min, Max and Default values are shown in SI units
