Trane RTHD

106 RTHD-SVX01D-EN
TechView
Feature
Settings
Chilled Water Reset (Constant, Outdoor,
Return, Disable),
Disable
Enum
Return Reset Ratio (10, 120), 50 % Percent
Return Start Reset (2.22, 16.67), 5.56 °C Diff Temperature
Return Max Reset (0.0, 11.11), 2.78 °C Diff Temperature
Outdoor Reset Ratio (-80, 80), 10 % Percent
Outdoor Start Reset (10, 54.44), 32.22 °C Temperature
Outdoor Max Reset (0.0, 11.11), 2.78 °C Diff Temperature
External Chilled Water Setpoint (Enable, Disable),
Disable
Enum
External Current Limit Setpoint (Enable, Disable),
Disable
Enum
Ice Building Feature (Enable, Disable),
Disable
Enum
External Base Loading Setpoint Enable (Enable, Disable),
Disable
Enum
Capacity Control Softloading Time (0, 7200), 900 sec Seconds
Current Limit Control Softloading Time (0, 7200), 600 sec Seconds
Current Limit Softload Start Point (40, 100), 40 %RLA Percent RLA
Phase Unbalance Limit Protection (Enable, Disable),
Enable
Enum
Over/Under Voltage Protection (Enable, Disable),
Disable
Enum
Condenser
Head
Pressure
(optional)
"Off State" Output Command (0.0-10.0), 2.0 Volts Voltage
Output Voltage at Desired Minimum Flow (0.0 - 10.0) 2.0 Volts Voltage
Desired Minimum Flow (0-100), 20 % Percent
Output Voltage at Desired Maximum Flow (0.0 - 10.0), 2.0 Volts Voltage
Actuator Stroke Time (0.0 - 300) 30 Sec Seconds
Damping Coefficient (0.1 - 1.8) 0.5 None
Table 22 Setpoint View Items
Tab Setpoint
(Min, Max), Default Units
Min, Max and Default values are shown in SI units
