Trane RTHD

14 RTHD-SVX01D-EN
General Information
Table 3 General Data
Unit Designator (corresponds to digits 6, 7, 14, 15, 21, 22 of unit model number)
D1D1E1 D1F1F2 D1G1G1 D1G2G2 D2D2E2 D2F2F3 D2G3G3
General
Refrigerant Type HFC-134a HFC-134a HFC-134a HFC-134a HFC-134a HFC-134a HFC-134a
Refrigerant Charge
(lb (kg))
475 (216) 625 (284) 700 (318) 700 (318) 475 (216) 625 (284) 700 (318)
Oil Charge (gal (l)) 6 (23) 10 (38) 11 (42) 11 (42) 6 (23) 10 (38) 11 (42)
Operating Weight
(lb (kg))
15385 (6978) 17537 (7955) 20500 (9299) 21065 (9555) 15570 (7063) 18220 (8265) 21641
(9816)
Shipping Weight
(lb (kg))
14443 (6551) 16187 (7342) 18600 (8437) 19107 (8667) 14562 (6605) 16820 (7630) 19508
(8849)
Overall Dimensions
Length (in(mm))*
126 (3189) 144 (3669) 146 (3712) 146 (3712) 126 (3189) 144 (3669) 146 (3712)
Width (in (mm))*
68 (1717) 68 (1716) 70 (1771) 70 (1771) 68(1717) 68 (1716) 70 (1771)
Height (in (mm))*
76 (1717) 76 (1716) 80 (2033) 80 (2033) 76 (1937) 76 (1936) 80 (2033)
Evaporator
Water Storage (gal
(l))
69 (261) 102 (386) 136 (515) 144 (545) 74 (280) 107 (405) 159 (602)
Minimum Flow
(gpm (l/s))
Water
415 (26) for
2-pass
563 (36)
2-pass
505 (35)
3 pass
550 (35) for
3-pass
450 (28) for
2-pass
604 (38) for
2-pass
622 (39) for
3-pass
275 (17) for
3-pass
376 (24)
3-pass
379 (24)
4 pass
411 (26) for
4-pass
300 (20) for
3-pass
404 (25) for
3-pass
466 (29) for
4-pass
Minimum Flow
(gpm (l/s))Brine
498 (31) for
2-pass
676 (43)
2-pass
606 (38)
3 pass
660 (42) for
3-pass
541 (34) for
2-pass
725 (46) for
2-pass
747 (47) for
3-pass
330 (21) for
3-pass
454 (29)
3-pass
454 (29)
4 pass
492 (31) for
4-pass
357 (23) for
3-pass
487 (31) for
3-pass
557 (35) for
4-pass
Maximum Flow
(gpm (l/s))
1812 (114)
for 2-pass
2478 (156)
for 2-pass
2218
3 pass
2413 (152)
for 3-pass
1980 (125)
for 2-pass
2667 (168)
for 2-pass
2732 (172)
for 3-pass
1206 (76)
for 3-pass
1655 (104)
for 3-pass
1666
4 pass
1807 (114)
for 4-pass
1320 (83)
for 3-pass
1780 (112)
for 3-pass
2050 (129)
for 4-pass
Condenser (all are 2-pass)
Water Storage
(gal (l))
44 (166) 57 (216) 79 (299) 91 (344) 47 (178) 61 (231) 97 (367)
Minimum Flow
(gpm (l/s))Water
291 (18) 355 (22) 444 (28) 535 (34) 316 (20) 385 (24) 589 (37)
Minimum Flow
(gpm (l/s))Brine
350 (22) 430 (27) 530 (33) 650 (41) 380 (24) 460 (29) 710 (45)
Max Flow (gpm
(l/s))
1280 (81) 1560 (98) 1960 (124) 2360 (149) 1390 (88) 1700 (107) 2600 (164)
All weights ±3%, include standard 150 psig water boxes.
Operating weights include refrigerant, oil, and water charges.
If oil cooler is installed, add 1/4 gal (1 liter) to the oil charge value given for B family units; add 1.0 gal (4 liters) for all other units.
Overall dimensions are based on 3-pass evap/2 pass cond and LH/RH water connections. Refer to submittals for exact job conf.
