General Information
Table 4 General Data
Unit Designator (corresponds to digits 6, 7, 14, 15, 21, 22 of unit model number)
D2G2G1 D3D2E2 D3F2F3 D3G2G1 D3G3G3 E3D2E2 E3F2F3 E3G2G1 E3G3G3
General
Refrigerant Type HFC-134a HFC-134a HFC-134a HFC-134a HFC-134a HFC-134a HFC-134a HFC-134a HFC-134a
Rfgt Chg (lb (kg)) 700 (318) 475 (216) 625 (284) 700 (318) 700 (318) 475 (216) 625 (284) 700 (318) 700 (318)
Oil Charge (gal (l)) 11 (42) 6 (23) 10 (38) 11 (42) 11 (42) 6 (23) 10 (38) 11 (42) 11 (42)
Operating Weight
(lb (kg))
20700
(9389)
15570
(7063)
18220
(8265)
20700
(9389)
21641
(9816)
15728
(7134)
18356
(8326)
20800
(9435)
21786
(9882)
Shipping Weight
(lb (kg))
18700
(8482)
14562
(6605)
16820
(7630)
18700
(8482)
19508
(8849)
14720
(6677)
16956
(7695)
18800
(85528)
19653
(8915)
Overall Dimensions
Length (in (mm))
146 (3712) 126 (3189) 144 (3669) 146 (3712) 146 (3712) 126 (3189) 144 (3669) 146 (3712) 146 (3712)
Width (in (mm))
70 (1771) 68 (1717) 68 (1716) 70 (1771) 70 (1771) 68 (1717) 67 (7716) 70 (1771) 70 (1771)
Height (in (mm))
80 (2033) 76 (1937) 76 (1936) 80 (2033) 80 (2033) 76 (1937) 76 (1936) 80 (2033) 80 (2033)
Evaporator
Water Storage
(gal (l))
144 (545) 74 (280) 107 (405) 144 (545) 159 (602) 74 (280) 107 (405) 144 (545) 159 (602)
Minimum Flow
(gpm (l/s))Water
550 (35)
3-pass
405 (28) for
2-pass
604 (38)
2-pass
550 (35)
3-pass
622 (39)
3-pass
405 (28)
2-pass
604 (38)
2-pass
550 (35)
3-pass
622 (39)
3-pass
411 (26)
4-pass
300 (19) for
3-pass
404 (25)
3-pass
411 (26)
4-pass
466 (29)
4-pass
300 (19) 3-
pass
404 (25)
3-pass
411 (26)
4-pass
466 (29)
4-pass
Minimum Flow
(gpm (l/s))Brine
660 (42)
3-pass
541 (34) for
2-pass
725 (46)
2-pass
660 (42)
3-pass
747 (47)
3-pass
541 (34) 2-
pass
725 (46)
2-pass
660 (42)
3-pass
747 (47)
3-pass
492 (31)
4-pass
357 (23) for
3-pass
487 (31)
3-pass
492 (31)
4-pass
557 (35)
4-pass
357 (23)
3-pass
487 (31)
3-pass
492 (31)
4-pass
557 (35)
4-pass
Max Flow
(gpm (l/s))
2413 (152)
for 3-pass
1980 (125)
for 2-pass
2667 (168)
for 2-pass
2413 (152)
for 3-pass
2732 (172)
for 3-pass
1980 (125)
2-pass
2667 (168)
for 2-pass
2413 (152)
for 3-pass
2732 (172)
for 3-pass
1807 (114)
for 4-pass
1320 (83)
for 3-pass
1780 (112)
for 3-pass
1807 (114)
for 4-pass
2050 (129)
for 4-pass
1320 (83)
for 3-pass
1780 (112)
for 3-pass
1807 (114)
for 4-pass
2050 (129)
for 4-pass
Condenser (all are 2-pass)
Water Storage
(gal (l))
79 (299) 47 (178) 61 (231) 79 (299) 97 (367) 47 (178) 61 (231) 79 (299) 97 (367)
Minimum Flow
(gpm (l/s))Water
444 (28) 316 (20) 355 (22) 444 (28) 589 (37) 316 (20) 355 (22) 444 (28) 589 (37)
Min Flow
(gpm (l/s))Brine
530 (33) 380 (24) 460 (29) 530 (33) 710 (45) 380 (24) 460 (29) 530 (33) 710 (45)
Max Flow
(gpm(l/s))
1960 (124) 1390 (88) 1700 (107) 1960 (124) 2600 (164) 1390 (88) 1700 (107) 1960 (124) 2600
(164)
All weights ±3%, include standard 150 psig water boxes.
Operating weights include refrigerant, oil, and water charges.
If oil cooler is installed, add 1/4 gal (1 liter) to the oil charge value given for B family units; add 1.0 gal (4 liters) for all other units.
Overall dimensions are based on 3-pass evap/2 pass cond and LH/RH water connections. Refer to submittals for exact job configurations
