Trane RTHD

38 RTHD-SVX01D-EN
Installation Mechanical
Table 10 Evaporator and Condenser Data
Compress
or Frame
Code
(Digit 6,7
of Model
No.)
Evap Shell
Code (Digits
14, 15 of
Model No.)
Evap.
Shell
Diameter
(in)
Nominal Connector
size (NPS)*
Cond Shell
Code
(Digits 21,22 of
Model No.)
Cond.
Shell
Diameter
(in)
Nom.
Conn.
Size
(NPS)*
2-
Pass
3-
Pass
4-
Pass 2-Pass
E3 D2 26.5 8 8 - E2 22.0 8
F2 29.0 8 8 - E2 22.0 8
G2 33.5 - 10 8 G1 25.75 8
G3 33.5 - 10 8 G3 25.75 8
D3 D2 26.5 8 8 - E2 22.0 8
F2 29.0 10 8 - F3 22.0 8
G2 33.5 - 10 8 G1 25.75 8
G3 33.5 - 10 8 G3 25.75 8
D2 D2 26.5 8 8 - E2 22.0 8
F2 29.0 10 8 - F3 22.0 8
G2 33.5 - 10 8 G1 25.75 8
G3 33.5 - 10 8 G3 25.75 8
D1 D1 26.5 8 8 - E1 22.0 8
F1 29.0 10 8 - F2 22.0 8
G1 33.5 - 10 8 G1 25.75 8
G2 33.5 - 10 8 G2 25.75 8
C2 D3 26.5 8 8 - E3 22.0 8
D4 26.5 8 8 E4 22.0 8
F2 29.0 10 8 - F3 22.0 8
C1 D6 26.5 8 8 - E5 22.0 8
D5 26.5 8 8 - E4 22.0 8
E1 33.5 8 8 - F1 22.0 8
B2 C2 23.0 - 6 - D2 18.75 6
B2 23.0 - 6 - B2 18.75 6
B1 C1 23.0 - 6 - D1 18.75 6
B1 23.0 - 6 - B1 18.75 6
Metric Conversion is:
6 NPS = 150 mm nominal
8 NPS = 200 mm nominal
10 NPS = 250 mm nominal
