Trane RTHD Installation Operation & Maintenance

RTHD-SVX01D-EN 9
General Information
Compressor Model Number (located on compressor nameplate):
Table 1 Compressor Model Number
Selection Category M/N Digit M/N Code Description of Selection
Compressor Series 1-4 CHHC Semi-Hermetic Heli-Rotor Compressor
Design Control 5 1 Pueblo
Compressor Frame 6 B B Frame
CC Frame
DD Frame
EE Frame
Compressor Capacity 7 1 Smaller capacity (minor)
2 Larger capacity (major)
3 Special 50 Hz capacity
Motor 8 A 200V/60Hz/3
C 230V/60Hz/3
D 380V/60Hz/3
F 460V/60Hz/3 or 400V/50Hz/3
H 575V/60Hz/3
Specials 9 O No Specials
C Specials Denoted Elsewhere
S Uncategorized Special not denoted elsewhere
Design Sequence 10-11 AO 1st Design (Factory Input)

Trane RTHD Specifications

General

Type	Water-Cooled Chiller
Refrigerant	R-134a
Compressor Type	Helical Rotary (Screw)
Voltage Options	200, 230, 380, 460, 575
Capacity Range	200 - 4000 tons (703 kW - 14, 060 kW)
