Page #11 background image
PKG-SVX027D-EN
11
Table 1. SCWM water-cooled self-contained (continued)
Tonnage
25 30 35 40L 40 50L 50 60L 60
70L
(a)
70
80L
(a)
80
Filter Data, Water-Cooled Units
Number -
Size (in.)
9 - 24 x 20 12 - 24 x 20 15 - 24 x 24
Number of Compressors
10 HP -
Variable
Speed
0 1 1 1 0 1 0 1 0 1 0 1 0
15 HP -
Variable
Speed
1 0 0 0 1 0 1 0 1 0 1 0 1
13 HP - Fixed
Speed
0 1 0 0 0 2 2 0 0 3 3 0 0
15 HP - Fixed
Speed
0 0 1 1 1 0 0 2 2 0 0 3 3
Number of Fans/Unit
No. of fans 2 3 4 5
Note: All performance data is provided in the Performance Selection Program. Contact Trane Sales at 770-988-8338 for more information.
(a)
Split coils.
(b)
All performance data is provided in the Performance Selection Program. Contact MJC Sales at 770-988-8338 for more information.
(c)
Minimum air flow at part load is 35% of full load design CFM.
(d)
Refrigerant charge shown is a general guideline, charge to sub-cooling as described in IOM. Note that occasionally a TXV adjustment may need to be made but only after
adequate sub-cooling has been reached.
Table 2. SCWM EER/IEER ratings
Tonnage
Model Number
Nameplate Voltage
EER
IEER (VAV)
AHRI Net Cooling
Capacity (BTUH)
25
SCWMN025F 208-230/60/3 14 18.5 269
SCWMN0254 460/60/3 14 18.5 269
30
SCWMN030F Low MCA 208-230/60/3 16.2 20.3 376
SCWMN0304 Low MCA 460/60/3 16.2 20.3 376
35
SCWMN035F Low MCA 208-230/60/3 15.6 20.3 407
SCWMN0354 Low MCA 460/60/3 15.6 20.3 407
40
SCWMN04LF Low MCA 208-230/60/3 15.8 20.6 408
SCWMN040F 208-230/60/3 14.8 20.6 468
SCWMN04L4 Low MCA 460/60/3 15.8 20.6 408
SCWMN0404 460/60/3 14.8 20.6 468
50
SCWMN05LF Low MCA 208-230/60/3 15.8 19.5 540
SCWMN050F 208-230/60/3 14.9 19.5 600
SCWMN05L4 Low MCA 460/60/3 15.8 19.5 540
SCWMN0504 460/60/3 14.9 19.5 600
60
SCWMN06LF Low MCA 208-230/60/3 15.7 18.5 636
SCWMN060F 208-230/60/3 14.8 18.5 696
SCWMN06L4 Low MCA 460/60/3 15.7 18.5 636
SCWMN0604 460/60/3 14.8 18.5 696
