Trane SCWM Series User Manual

PKG-SVX027D-EN
23
Weights
Table 10. Unit weights
Unit Size
Base Weight
Waterside Economizer
(lbs) (kg) (lbs) (kg)
25 Ton 2138 970 204 93
30 Ton 2688 1219 228 104
35 Ton 2688 1219 228 104
40 Ton 3041 1379 381 173
50 Ton 3506 1590 468 212
60 Ton 3641 1652 568 258
70 Ton 4733 2146 762 346
80 Ton 4733 2146 762 346
Note: All unit weights include refrigerant, water, and controllers.
Table 11. Unit shipping weights (fan cassette)
Unit Size
Overall Dimensions (in)
Unit Weight
(lbs)
Fan Cassette (in)
Number
of Dual
Fan Weight
(Two Fans)
Number
of Single
Fan Weight
(Single Fan)
Total Fan
Weight
(lbs)
25 Ton 70" x 84" x 56" 2030 34.5"x 54.5"x 27.6" - - 1 308 308
30 Ton 70" x 84" x 68" 2580 34.5"x 54.5"x 27.6" 1 408 - - 408
35 Ton 70" x 84" x 68" 2580 34.5"x 54.5"x 27.6" 1 408 - - 408
40 Ton 70"x 84" x 95.5" 2933 34.5"x 54.5"x 27.6" 1 408 1 308 716
50 Ton 70"x 84" x 95.5" 3365 34.5"x 54.5"x 27.6" 1 408 1 308 716
60 Ton 70"x 84" x 95.5" 3500 34.5"x 54.5"x 27.6" 2 408 - - 816
70 Ton 70"x 84" x 126" 4545 34.5"x 54.5"x 27.6" 2 408 1 308 1124
80 Ton 70"x 84" x 126" 4545 34.5"x 54.5"x 27.6" 2 408 1 308 1124
Table 12. Unit shipping weights (compressor cassette)
Unit Size
Overall Dimensions
(in)
Unit Weight
(lbs)
Compressor Cassette
(in)
Number
Fixed Spd
FS Condensing
Unit Cassette
Number
Var Spd
VS Condensing
Unit Cassette
Total Condensing
Unit Weight (lbs)
25 Ton 70" x 84" x 56" 2030 34.5"x 29.5"x 27.6" - - 1 335 335
30 Ton 70" x 84" x 68" 2580 34.5"x 29.5"x 27.6" 1 385 1 335 720
35 Ton 70" x 84" x 68" 2580 34.5"x 29.5"x 27.6" 1 385 1 335 720
40 Ton 70"x 84" x 95.5" 2933 34.5"x 29.5"x 27.6" 1 385 1 335 720
50 Ton 70"x 84" x 95.5" 3365 34.5"x 29.5"x 27.6" 2 385 1 335 1105
60 Ton 70"x 84" x 95.5" 3500 34.5"x 29.5"x 27.6" 2 385 1 335 1105
70 Ton 70"x 84" x 126" 4545 34.5"x 29.5"x 27.6" 3 385 1 335 1490
80 Ton 70"x 84" x 126" 4545 34.5"x 29.5"x 27.6" 3 385 1 335 1490
Table 13. Unit shipping weights (starter cassette)
Unit
Size
Overall Dimensions (in) Unit Weight (lbs) Starter Cassette (in)
Starter Cassette
Weight (230 Vac) (lbs)
25 Ton 70" x 84" x 56" 2030 34.5"x 54.5"x 27.6" 323
30 Ton 70" x 84" x 68" 2580 34.5"x 54.5"x 27.6" 323
35 Ton 70" x 84" x 68" 2580 34.5"x 54.5"x 27.6" 323
