Trane SCWM Series User Manual

10
PKG-SVX027D-EN
General Data
Table 1. SCWM water-cooled self-contained
Tonnage
25 30 35 40L 40 50L 50 60L 60
70L
(a)
70
80L
(a)
80
Compressor Data
Quantity
1VS 1VS-1FS 1VS-1FS 1VS-1FS 1VS-1FS 1VS-2FS 1VS-2FS 1VS-2FS 1VS-2FS 1VS-3FS 1VS-3FS 1VS-3FS 1VS-3FS
Nominal
Capacity
15 10-13 10-15 10-15 15-15 10-13 15-13 10-15 15-15 10-13 15-13 10-15 15-15
Circuits 1 2 2 2 2 3 3 3 3 4 4 4 4
Evaporator Coil Data
Rows 4 4 4 4 4 3 3 4 4 4 4 4 4 4 4 4 4
Sq. Ft.
15.0 19.8 19.8 25.5 25.5 33 33 38 38 19.8 33.3 19.8 33.3 19.8 33.3 19.8 33.3
Fins/in 13.0 13.5 13.5 13.5 13.5 13.5 13.5 13.5 13.5 13.5 13 13.5 13.5 13.5 13.5 13.5 13.5
Number of
Coils
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Condenser Data
Minimumum
GPM w/o
Econ
(b)
N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
Minimum
GPM w/ Econ
N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
Maximum
GPM
70 140 140 140 140 210 210 210 210 280 280 280 280
Evaporator Fan Data
Quantity
1 2 2 3 3 3 3 4 4 5 5 5 5
Diameter
500
mm
500 mm 500 mm 500 mm 500 mm 500 mm 500 mm 500 mm 500 mm 500 mm 500 mm 500 mm 500 mm
Power
Consumption
kW
6.4 6.4 6.4 6.4 6.4 6.4 6.4 6.4 6.4 6.4 6.4 6.4 6.4
Minimum
Design cfm
(c)
6875 8250 9625 11000 11000 13750 13750 16500 16500 19250 19250 22000 22000
Maximum
Design cfm
10000 12000 14000 16000 16000 20000 20000 24000 24000 28000 28000 32000 32000
Refrigerant Charge, lbs. R-410A
(d)
Circuit A 18 17 17 17 18 17 18 17 18 20 21 20 21
Circuit B x 18 18 19 19 18 18 19 19 18 18 19 19
Circuit C x x x x x 18 18 19 19 18 18 19 19
Circuit D x x x x x x x x x 17 17 18 18
