Trane SCWM Series - Instructions; Start-Up Log

64
PKG-SVX027D-EN
Operating and Programming Instructions
See Self-Contained Programming Guide, PKG-SVP01*-
EN, for available unit operating setpoints and instructions.
A copy ships with each unit. For units with VFD option, see
installer guide that ships with each VFD.
Start-Up Log
Unit:
Unit Location:
Unit Voltage
Evaporator
Evaporator fan motor horsepower:
Evaporator fan motor amps:
Evaporator fan rpm (actual):
Evaporator system static (from test and balance
report or actual readings)
Supply duct static: Return duct static:
Evaporator system cfm (test and balance sheet or
actual tested):
Evaporator Air Conditioners (with all compressor operating)
Entering Leaving
Dry-bulb °F: Dry-bulb °F:
Wet-bulb °F: Wet-bulb °F:
Water-Cooled Units
Circuit A Circuit B Circuit C Circuit D
Entering water temp °F
Leaving water temp °F
Entering water pressure
psig
Leaving water pressure
psig
Start-Up
