Selection Procedures
• RLA = Rated Load Amps
• Compressor LRA = Locked Rotor Amps
• Compressor Input = VFD drive Input
• Compressor Output = VFD drive output
• Voltage utilization range is ±10%
Determination of Minimum Circuit
Ampacity (MCA)
MCA = 1.25 x Largest motor amps/VFD Input + the sum of
the remaining motor amps.
Determination of Max Fuse (MFS) and Max
Circuit Breaker (MCB) Sizes
MFS and MCB = 2.25 x Largest motor amps (RLA)/VFD
input) + the sum of the remaining motor amps.
If the rating value calculation does not equal a standard
over current protective device rating, use the next lower
standard rating as the maximum.
Table 15. Electrical service sizing data — motors
Tonnage
Model Number
Unit Wiring
Motor Data
Compressor (EA) Fan (EA)
Fixed Speed Variable Speed
VSD
Nameplate
Voltage
Voltage
Range
MCA MOP Disc
Qty
RLA LRA
Qty
Max
Input (A)
Qty
kW FLA
25
SCWMN025F 208-230/60/3 187-253 128.0 211 200 NA - - 1 84 1 6.15 18.6
SCWMN0254 460/60/3 414-506 86.0 146 100 NA - - 1 60 1 6.15 9
30
SCWMN030F Low MCA 208-230/60/3 187-253 163.0 218 200 1 51.28 300 1 56 2 6.15 18.6
SCWMN0304 Low MCA 460/60/3 414-506 81.0 110 100 1 23.1 150 1 30 2 6.15 9
35
SCWMN035F Low MCA 208-230/60/3 187-253 167.0 223 200 1 55.77 340 1 56 2 6.15 18.6
SCWMN0354 Low MCA 460/60/3 414-506 81.0 111 100 1 23.72 110 1 30 2 6.15 9
40
SCWMN04LF Low MCA 208-230/60/3 187 - 253 186.6 250 200 1 55.77 340 1 56 3 6.15 18.6
SCWMN040F 208-230/60/3 187-253 221.6 300 225 1 55.77 340 1 84 3 6.15 18.6
SCWMN04L4 Low MCA 460/60/3 414 - 506 90.7 125 100 1 23.72 110 1 30 3 6.15 9
SCWMN0404 460/60/3 414-506 128.2 200 125 1 23.72 110 1 60 3 6.15 9
50
SCWMN05LF Low MCA 208-230/60/3 187 - 253 233.4 300 250 2 51.28 300 1 56 3 6.15 18.6
SCWMN050F 208-230/60/3 187-253 268.4 350 300 2 51.28 300 1 84 3 6.15 18.6
SCWMN05L4 Low MCA 460/60/3 414 - 506 113.2 150 125 2 23.1 150 1 30 3 6.15 9
SCWMN0504 460/60/3 414-506 150.7 200 150 2 23.1 150 1 60 3 6.15 9
60
SCWMN06LF Low MCA 208-230/60/3 187 - 253 260.9 300 300 2 55.77 340 1 56 4 6.15 18.6
SCWMN060F 208-230/60/3 187-253 295.9 375 300 2 55.77 340 1 84 4 6.15 18.6
SCWMN06L4 Low MCA 460/60/3 414 - 506 123.4 150 150 2 23.72 110 1 30 4 6.15 9
SCWMN0604 460/60/3 414-506 160.9 225 175 2 23.72 110 1 60 4 6.15 9
70
SCWMN07LF Low MCA 208-230/60/3 187-253 321.8 375 350 3 51.28 300 1 56 5 6.15 18.6
SCWMN070F 208-230/60/3 187-253 356.9 450 375 3 51.28 300 1 84 5 6.15 18.6
SCWMN07L4 Low MCA 460/60/3 414-506 154.2 175 175 3 23.1 150 1 30 5 6.15 9
SCWMN0704 460/60/3 414-506 191.7 250 200 3 23.1 150 1 60 5 6.15 9
Installation - Electrical
