Table 13. Unit shipping weights (starter cassette) (continued)
Unit
Size
Overall Dimensions (in) Unit Weight (lbs) Starter Cassette (in)
Starter Cassette
Weight (230 Vac) (lbs)
40 Ton 70"x 84" x 95.5" 2933 34.5"x 54.5"x 27.6" 323
50 Ton 70"x 84" x 95.5" 3365 34.5"x 54.5"x 27.6" 323
60 Ton 70"x 84" x 95.5" 3500 34.5"x 54.5"x 27.6" 323
70 Ton 70"x 84" x 126" 4545 34.5"x 54.5"x 27.6" 388
80 Ton 70"x 84" x 126" 4545 34.5"x 54.5"x 27.6" 388
Table 14. Unit shipping weights (evaporator cassette)
Tonnage Overall dimensions (in) Unit Weight (lbs) Evaporator Cassette (in)
Total Weight of
Cassette
(excl. Economizer) (lbs)
25 Ton 70" x 84" x 56" 2030 34.5" x 84" x 55.2" 1018
30 Ton 70" x 84" x 68" 2580 35.5" x 84" x 67.7" 1082
35 Ton 70" x 84" x 68" 2580 34.5" x 84" x 67.7" 1082
40 Ton 70"x 84" x 95.5" 2933 34.5" x 84" x 94" 1127
50 Ton 70"x 84" x 95.5" 3365 34.5" x 84" x 94" 1219
60 Ton 70"x 84" x 95.5" 3500 34.5" x 84" x 94" 1254
70 Ton
(a)
70"x 84" x 127" 4545
34.5" x 84" x 77" 1032
34.5" x 84" x 50" 620
80 Ton
(a)
70"x 84" x 127" 4545
34.5" x 84" x 77" 1032
34.5" x 84" x 50" 620
(a)
Split coils.
