Trane SCWM Series User Manual

12
PKG-SVX027D-EN
Table 2. SCWM EER/IEER ratings (continued)
Tonnage
Model Number
Nameplate Voltage
EER
IEER (VAV)
AHRI Net Cooling
Capacity (BTUH)
70
SCWMN07LF Low MCA 208-230/60/3 15.8 19.5 780
SCWMN070F 208-230/60/3 14.9 19.5 840
SCWMN07L4 Low MCA 460/60/3 15.8 19.5 780
SCWMN0704 460/60/3 14.9 19.5 840
80
SCWMN08LF Low MCA 208-230/60/3 15.7 20.8 876
SCWMN080F 208-230/60/3 14.7 20.8 936
SCWMN08L4 Low MCA 460/60/3 15.7 20.8 876
SCWMN0804 460/60/3 14.7 20.8 936
Notes:
1. Cooling only.
2. Cooling performance is rated at 80F EDB/67F EWB with 85 EWT for water-cooled performance and 95F Ambient for air-cooled performance.
3. EER, IEER, and AHRI Net Cooling Capacity are tested in accordance with the AHRI 340/360 (I-P) and certified to 10 CFR Part 431 from the US Department of
Energy.
Table 3. SCWM water volumes
Tonnage
Water Volume in U.S. Gallons/Liters
w/o Economizer
With Chem. Cleanable Econ, Add
Gallons Liters Gallons Liters
25 4.3 16.3 7.7 29.1
30 5.4 20.4 9.5 36.0
35 5.4 20.4 9.5 36.0
40 8.2 31.0 12 45.4
50 9.7 36.7 14.4 54.5
60 9.7 36.7 19.1 72.3
70 12.9 48.9 24.0 90.8
80 12.9 48.9 24.0 90.8
Table 4. SCWM refrigerant circuits, number of compressors by circuit
Tonnage
Model No.
Circuit
1 2 3 4
25 SCWMN025 1-15T VS N/A N/A N/A
30 SCWMN030 1-10T VS 1-13T FS N/A N/A
35 SCWMN035 1-10T VS 1-15T FS N/A N/A
40
SCWMN04L 1-10T VS 1-15T FS N/A N/A
SCWMN040 1-15T VS 1-15T FS N/A N/A
50
SCWMN05L 1-10T VS 1-13T FS 1-13T FS N/A
SCWMN050 1-15T VS 1-13T FS 1-13T FS N/A
60
SCWMN06L 1-10T VS 1-15T FS 1-15T FS N/A
SCWMN060 1-15T VS 1-15T FS 1-15T FS N/A
70
SCWMN07L 1-10T VS 1-13T FS 1-13T FS 1-13T FS
SCWMN070 1-15T VS 1-13T FS 1-13T FS 1-13T FS
80
SCWMN08L 1-10T VS 1-15T FS 1-15T FS 1-15T FS
SCWMN080 1-15T VS 1-15T FS 1-15T FS 1-15T FS
Note: VS - Variable Speed Compressor, S - Fixed Speed Compressor
