Trane SCWM Series - Page 13

PKG-SVX027D-EN
13
Table 5. Waterside economizer coil physical data
Model Unit Size Rows FPF
Height Length
MSC 25 Ton 4 150 72 30
MSC 30 Ton 4 150 75 38
MSC 35 Ton 4 150 75 38
MSC 40 Ton 4 150 75 49
MSC 50 Ton 4 150 75 65
MSC 60 Ton 4 150 75 73
MSC
(a)
70 Ton
4 150 75 38
4 150 75 64
MSC
(a)
80 Ton
4 150 75 38
4 150 75 64
(a)
Split coils.
Table 6. Hot water coil physical data
Model Unit Size Rows FPF
Height Length
MSC 25 Ton 1 156 72 30
MSC 30 Ton 1 156 75 38
MSC 35 Ton 1 156 75 38
MSC 40 Ton 1 156 75 49
MSC 50 Ton 1 156 75 65
MSC 60 Ton 1 156 75 73
MSC
(a)
70 Ton
1 156 75 45
1 156 75 45
MSC
(a)
80 Ton
1 156 75 45
1 156 75 45
(a)
Split coils.
Important: All performance data is provided in the
Performance Selection Program. Contact your
local Trane Sales office for more information.
General Data
