Temperature Limit Switch Usage for Gas
Heat Units
Units are factory shipped in the downflow discharge
configuration but can be field converted to a horizontal
discharge configuration. Some, but not all units require a
different TCO1 limit switch, which is attached to the
combustion blower motor if horizontal discharge
configuration is used.
If any of the units are installed in the downflow discharge
con
figuration and have the alternate TCO1 limit switch
provided, remove the additional TCO1 limit switch from
the combustion blower motor and discard.
Table 5. TC01 tripping values
Unit Model - 6 to 10 Ton
Standard Efficiency
TCO1 Tripping Values -
Downflow/ Horizontal
YSC072H**(M,Y) 155F/170F
YSC072H**(L,X) 170F
YSC072H**(H,Z) 145F/155F
YSC090H**(L,X) 180F/200F
YSC090H**(M,Y) 155F
YSC090H**(H,Z) 155F
YSC092H**(L,X)
(a)
(a) Digit 15 = 0,1
200F/220F
YSC092H**(L,X)
(b)
(b) Digit 15 = 6,7
225F
YSC092H**(M,Y)(a) 230F
YSC092H**(M,Y)(b) 190F/225F
YSC092H**(H,Z)(a) 220F/260F
YSC092H**(H,Z)(b) 220F/260F
YSC102H**(L,X)(a) 200F/220F
YSC102H**(L,X)(b) 225F
YSC102H**(M,Y)(a) 230F
YSC102H**(M,Y)(b) 190F/225F
YSC102H**(H,Z)(a) 220F/260F
YSC102H**(H,Z)(b) 220F/260F
YSC120H**(L,X) 190F/225F
YSC120H**(M,Y) 200F
YSC120H**(H,Z) 150F/210F
Table 6. TC01 tripping values
(a),(b)
Unit Model - High Efficiency
15 SEER
TCO1 Tripping Values -
Downflow/ Horizontal
YHC036E**(L,X)-DD 180F
YHC036E**(L,X)-BD 170F
YHC036E1*(M,Y)-DD
YHC036E(3,4,W)*(M,Y)-DD
190F
170F/190F
YHC036E**(M,Y)-BD 180F/190F
YHC036E1*(H,Z)-DD
YHC036E(3,4,W)*(H,Z)-DD
190F/220F
170F/190F
YHC036E**(H,Z)-BD 155F/190F
YHC048F1*(L,X)-DD
YHC048E/F(3,4,W)*(L,X)-DD
170F/155F
145F/155F
YHC048E/F**(L,X)-BD 155F
YHC048F1*(M,Y)-DD
YHC048E/F(3,4,W)*(M,Y)-DD
140F
150F/170F
YHC048E/F**(M,Y)-BD 170F/180F
YHC048F1*(H,Z)-DD
YHC048E/F(3,4,W)*(H,Z)-DD
180F/200F
220F
YHC048E/F**(H,Z)-BD 220F/260F
YHC060F1*(L,X)-DD
YHC060E/F(3,4,W)*(L,X)-DD
155F
140F
YHC060E/F**(L,X)-BD 155F/145F
YHC060F1*(M,Y)-DD
YHC060E/F(3,4,W)*(M,Y)-DD
140F/150F
145F/170F
YHC060E/F**(M,Y)-BD 170F
YHC060F1*(H,Z)-DD
YHC060E/F(3,4,W)*(H,Z)-DD
180F
190F/220F
YHC060E/F**(H,Z)-BD 220F/230F
YHC072E/F**(L,X) 200F
YHC072E/F**(M,Y) 220F
YHC072E/F**(H,Z) 210F
YHC074F**(L,X) 170F
YHC074F**(M,Y) 180F/190F
YHC074F**(H,Z) 180F/230F
YHC092F**(L,X) 200F/220F
YHC092F**(M,Y) 190F/225F
YHC092F**(H,Z) 200F
YHC102F**(L,X) 200F/220F
YHC102F**(M,Y) 190F/225F
YHC102F**(H,Z) 200F
YHC120F**(L,X) 170F/200F
YHC120F**(M,Y) 170F/190F
YHC120F**(H,Z) 135F/155F
(a) BD= Belt drive ID motor
(b) DD= Direct drive ID motor
Table 7. TC01 tripping values
Unit Model - High Efficiency
17 Plus
TCO1 Tripping Values -
Downflow/ Horizontal
YHC037***(L,X) 190F
YHC037***(M,Y) 170F/220F
YHC037***(H,Z) 220F
YHC047***(L,X) 145F/155F
YHC047***(M,Y) 170F
YHC047***(H,Z) 220F
YHC067***(L,X) 140F
YHC067***(M,Y) 170F
YHC067***(H,Z) 170F
Table 6. TC01 tripping values
(a),(b)
(continued)
Unit Model - High Efficiency
15 SEER
TCO1 Tripping Values -
Downflow/ Horizontal
