80 RT-SVX21AC-EN
Wiring Diagrams
Table 29. Wiring diagram matrix
(a)
Schematic Type
Drawing
Number Description
Control ReliaTel™ 230,460,575V
1213-1641 YSC036-060G ReliaTel controls
Control ReliaTel™ 230,460,575V
4366-7217 YHC(037-067)
Control ReliaTel™ 230,460,575V
4366-4571
Y(S,H)C(036,048)E/F (1,3 Phase) and YHC060F (1-Phase),
ReliaTel Cont
rols, X13 IDM
Control ReliaTel™ 230,460,575V
4366-1015 Y(S,H)C(036-090)E/F, ReliaTel Controls, Belt-Drive IDM
Control ReliaTel™ 230,460,575V
4366-4703
YSC060E (1,3 Phase) and YHC060E/F (3-Phase), Reli
aTel
Controls, X13 IDM
Control ReliaTel™ 230,460,575V
1213-2389 YSC(072-090)H ReliaTel Gas Heat
Control ReliaTel™ 230,460,575V
1213-2391 YSC(092-120)H ReliaTel Gas Heat
Control ReliaTel™ 230,460,575V
4366-1042 YSC(092,102)F, ReliaTel Controls
Control ReliaTel™ 230,460,575V
4366-7436 (YHC074-102,YSC120)F, ReliaTel Controls
Control ReliaTel™ 230V/460V
1213-2411 YHC120F, ReliaTel Controls
Control ReliaTel™ 575V
1213-2412 YHC120F, ReliaTel Controls
Control Electromechanical 230,460,575V
1213-1644 YSC(036-060)G Electromechanical Controls
Control Electromechanical 230,460,575V
4366-8386
Y(S,H)C(036,048)E/F (1,3 Phase) and YHC060F (1-Phase),
Electrom
echanical Controls, X13 IDM
Control Electromechanical 230,460,575V
4366-8383
Y(S,H)C(036-060)E/F, Electromechanical Controls, Belt-
Drive IDM
Control Electromechanical 230,460,575V
4366-8387
YSC060E (1,3 Phase) and YHC060E/F (3-Phase),
Electrom
echanical Controls, X13 IDM
Control Electromechanical 230,460,575V
4366-8385 Y(S,H)C(072,090)F, Electromechanical Controls
Control Electromechanical 230,460,575V
1213-2414 YSC(072-120)H Electromechanical Gas Heat
Control Electromechanical 230,460,575V
4366-8384 YSC(092,102)F, Electromechanical Controls
Control Electromechanical 230,460,575V
4366-8388 (YHC074-102,YSC120)F, Electromechanical Controls
Control Electromechanical 230V/460V
1213-2409 YHC120F, Electromechanical Controls
Control Electromechanical 575V
1213-2410 YHC120F, Electromechanical Controls
Control ReliaTel™ 230, 460V
1213-3640
Ultra Low NOx, 3, 4, & 5 TON,
208-230/60/3, 460/60/3, YHC(037-067)E(3,4), 17-SEER
Power ReliaTel™ 230V
1213-3644
Ultra Low NOx, 3, 4 & 5 TON, 230/60/3,
YHC(037-067E)3, 17-SEER
Power ReliaTel™ 460V
1213-3645
Ultra Low NOx, 3, 4 & 5 TON, 460/60/3,
YHC(037-067E)4, 17-SEER
Power ReliaTel™ 230V
1213-1637 YSC(036-060)G3 ReliaTel Controls
Power ReliaTel™ 230V
4366-7179 YHC(037-067) (230V)
Power ReliaTel™ 230V
4366-4576 Y(S,H)C(036-060)E/F (1-Phase)
Power ReliaTel™ 230V
4366-5163 YHC(036-060)E/F (230V 3-Phase), X13 IDM
Power ReliaTel™ 230V
4366-1016 Y(S,H)C(036-090)E/F (230V 3-Phase), Belt-Drive IDM
Power ReliaTel™ 230V
4366-1033 YSC(092,102)F (230V)
Power ReliaTel™ 230V
1213-2280 (YHC074-102, YSC120)F (230V), ReliaTel Controls
Power ReliaTel™ 230V
1213-2411 YHC120F, ReliaTel Controls
Power ReliaTel™ 460V and/or 575V
1213-1638 YSC(036-060)G4 ReliaTel Controls
Power ReliaTel™ 460V and/or 575V
1213-1662 YSC(036-060)GW ReliaTel Controls
Power ReliaTel™ 460V and/or 575V
4366-7180 YHC(037-067) (460V)
Power ReliaTel™ 460V and/or 575V
4366-5164 YHC(036-060)E/F (460V), X13 IDM
Power ReliaTel™ 460V and/or 575V
4366-1005 Y(S,H)C(036-090)E/F (460V,575V), Belt-Drive IDM
Power ReliaTel™ 460V and/or 575V
4366-1034 YSC(092,102)F (460V,575V)
Power ReliaTel™ 460V and/or 575V
1213-2281 (YHC074-102, YSC120)F (460V), ReliaTel Controls
Power ReliaTel™ 460V and/or 575V
1213-2282 YSC120F (575V), ReliaTel Controls
Power ReliaTel™ 460V
1213-2411 YHC120F, ReliaTel Controls
Power ReliaTel™ 575V
1213-2412 YHC120F, ReliaTel Controls
Power Electromechanical 230V
1213-1637 YSC(036-060)G3 Electromechanical Controls
Power Electromechanical 230V
1213-2409 YHC120F, Electromechanical Controls
Power Electromechanical 230V
1213-2275 YHC(074-102)F, YSC120F, Electromechanical Controls
