45
10.2016
WTAL - TNX65/42
Maintenance work every 2 000 hours of operation
Covers in the working area
Check wiper (wiper lips and moulded wiper) on cover plates of main and
opposed spindle and replace if necessary.
This maintenance work can only be carried out when the machine is
switched on.
Damaged wipers must be replaced without delay.
Check wipers
• Apply a thin film of oil approx. 50 mm wide to the areas to be wiped.
• Wipe off the oil film by moving the slide approx. 30 mm.
• The wipers are OK if they wipe off the oil over the entire area.
D06
If not, the worn wipers must be replaced.
The Article Nos. of the required wipers can be found in the in the
Spare Parts List.
Replace wipers
• Set master switch to position "0" and lock it in position.
• Remove wipers.
• Remove any chips or impurities under the wiper and clean the guideways.
• Fit new wipers, pressing them firmly into place against the guideways.
• Set master switch to position "1".
• Check wipers again.
