16
1000BASE-T Port 1~24 Status LEDs
Link/ACT: Link/Activity
On : When the Link/ACT LED lights on, the respective port is
successfully connected to an Ethernet network.
Blinking : When the Link/ACT LED is blinking, the port is transmitting or
receiving data on the Ethernet network.
Off : No link.
Speed
Green : When the Speed LED lights green, the respective port is connected
to a 1000Mbps Gigabit Ethernet network.
Amber : When the Speed LED lights amber, the respective port is connected
to a 100Mbps Fast Ethernet network.
Off When the Speed LED lights off, the respective port is connected to a
10Mbps Ethernet network.
