Mini-GBIC Port 23 ~ 24 Status LEDs
Link/ACT
On : When the fiber line connected to the mini-GBIC module is installed
and connected to a network, the Link/ACT LED will lights on.
Blinking : When the Link/ACT LED is blinking, the port is transmitting or
receiving data on the Gigabit Ethernet network.
Off : Fiber line or mini-GBIC module is not installed.
Speed
Green : When the Speed LED lights green, the respective port is connected
to a 1000Mbps Gigabit Ethernet network.
Amber : When the Speed LED lights amber, the respective port is connected
to a 100Mbps Fast Ethernet network.
Off When the Speed LED lights off, the respective port is connected to a
10Mbps Ethernet network.
