TriangleTube Instinct Series Installation & Maintenance Manual

66
CHAPTER 13
CHAPTER 13 - EXTERNAL MODULATING CONTROL
DHW SETTING
FACTORY
DEFAULT
MINIMUM
SETTING
MAXIMUM
SETTING
EZ SETUP RESET INSTALLER RESET
DHW Operation Enabled
3
Demand Type Thermostat
DHW Boiler Setpoint 168°F [76°C] 96°F [35°C] 188°F [87°C]
3 3
DHW Setpoint 140°F [60°C] 68°F [20°C] 168°F [75°C]
3 3
DHW On Dierential 6°F [3°C] 4°F [2°C] 18°F [10°C]
3
DHW Storage Adder 28°F [15°C] 10°F [5°C] 54°F [30°C]
3
DHW Post Pump Time 2 Minutes Off 30 Minutes
3
DHW Priority Timeout O Off 120 Minutes
3 3
DHW Priority Enabled
3
DHW Call Blocking 0 Minute 0 Minute 30 Minutes
3
DHW to CH Call Blocking 1 Minute 0 Minute 30 Minutes
3
Antilegionella Function Disabled Enabled
3
BOILER SETTING
FACTORY
DEFAULT
MINIMUM
SETTING
MAXIMUM
SETTING
EZ SETUP RESET INSTALLER RESET
Lockout Temp. 210°F [99°C]
3
Modbus Address 0=BCST 0=BCST 247
3
Flex. Relay 1(CH) CH1
3
Flex. Relay 2(DHW) DHW
Flex. Relay 3(P3) CH1/CH2/DHW
Flex. Relay 4(ERR) ERROR
Flex. Relay 5(Flame) FLAME
Flex. Relay 6(P4) CH2
Error Relay
On Lockout, Blocking
and Warning
Pump PWM Minimum 30% 1% 100%
Ignition Level Varies by model
Mix Zone High Limit 114°F [45°C] 68°F [20°C] 176°F [80°C]
Appliance Setting Varies by model
CASCADE SETTING
FACTORY
DEFAULT
MINIMUM
SETTING
MAXIMUM
SETTING
EZ SETUP RESET INSTALLER RESET
Stage Delay 60 Seconds 0 Seconds 255 Seconds
3
Minimum Firing Rate 25% 0% 100%
3
Max. Firing Rate Varies by model 0 MBH [0kW] 869 MBH [255kW]
3
CH/DHW Boilers 0 0 6
3
Auto. Rotation Enabled
3
CH Prop. Gain 7 1 255
3
CH Integral Gain 245 1 255
3
DHW Prop. Gain 7 1 255
3
DHW Integral Gain 245 1 255
3
