Fig. 52 - Front View INSTINCT Combi 155

108

CHAPTER 19

CHAPTER 19 - PRODUCT SPECIFICATIONS

A B C D E F G H I J K L

Connection

Boiler

Width

3” Com-

bustion Air

Inlet

3” Vent

Outlet

3/4” NPSC

Relief Valve

Vent/Combus-

tion Air Adapt-

er Height

Boiler

Height

1" NPT Boil-

er Supply

1" NPT Boil-

er Return

3/4" NPT

Gas Con-

nection

Conden-

sate Drain

DHW

Inlet

DHW

Outlet

Dimension

inches

[mm]

21 /

[550]

[125.8]

[406.8]

2 /

[54.2]

5 /

[130]

32 /

[828.3]

2 /

[69.7]

19 /

[497.7]

[278]

8 /

[211.8]

1 /

[44.7]

16 /

[422.7]
