CHAPTER 3 - UNIT PREPARATIONS
3.5. Stud Walls - Installation
1. Locate the studs in the general area of the boiler
installation.
2. Place the wall-mounting bracket on the wall cen-
tering the mounting slots with the stud centers
and ensuring the upper edge of the bracket is away
from the wall.
3. Level the bracket, while maintaining it’s centering
with the studs and use a pencil to mark the location
of the mounting slots.
4. Remove the bracket from the wall and drill a 1/4” di-
ameter by 3” deep hole in the center of each mark.
For applications using metal studs and 3/16” toggle
bolts, drill the required clearance hole.
5. Reposition the bracket on the wall and align with
the mounting slots/holes. Insert the two lag screws
provided (or toggle bolts for metal studs) through
the mounting slots/holes and loosely tighten.
6. Level bracket and tighten screws (bolts for metal
studs) securely making sure not to over-tighten to
avoid damaging drywall or plaster.
3.6. Wall Bracket Installation - Solid Walls
1. Locate the general area of the boiler installation.
2. Place the wall-mounting bracket on the wall ensuring
the upper edge of the bracket is away from the wall.
3. Level the bracket and use a pencil to mark the loca-
tion of the mounting slots on the wall.
4. Remove the bracket from the wall and drill a 5/8”
diameter by 1-3/8” deep hole in the center of each
mark.
5. Install the provided anchors ush or slightly recessed
in the drilled holes with threaded side facing down.
6. Reposition the bracket on the wall and align with
the mounting slots/holes. Insert the two bolts with
washers through the mounting slots/holes and
loosely tighten.
7. Level bracket and tighten bolts securely.
3.7. Boiler Mounting
1. Obtain assistance in lifting the boiler onto the wall
bracket.
2. Install the boiler making sure the boiler mounting
lip located along the upper edge of the rear jacket
panel engages the wall-mounting bracket. Ensure
the boiler is seated properly and is secure.
3.4. Wall Mounting Guidelines
The wall-mounting bracket is designed for stud spacing
of approximate 12 inch or 16 inch on centers. For un-
conventional stud spacing, a solid / secure mounting
surface must be provided for installation of the bracket.
1. For applications using wood studs, install the brack-
et using the lag screws provided with the boiler.
Ensure both lag screws are installed securely in the
studs.
2. For applications using metal studs, install the brack-
et to the studs using 3/16” toggle bolts and wash-
ers.
3. DO NOT mount or attempt to mount the wall
bracket to hollow sheet rock or lath walls using
anchors. Only install boiler to studs or equivalent
wood structure.
4. For applications using solid walls (rock, concrete,
brick, cinder block, etc.), install the wall bracket us-
ing anchors (double expansion shields) and bolts
with washers provided with the boiler.
5. The boiler is too heavy and bulky for a single person
to lift and attempt to mount; a minimum of 2 peo-
ple are required for mounting the boiler.
Use extreme care not to drop the boiler or
cause bodily injury while lifting or mount-
ing the boiler onto the wall bracket. Once
mounted, verify that the boiler is securely
attached to the bracket and wall. Failure to
comply with the above guidelines can result
in substantial property damage, serious inju-
ry, or death.
WARNING
