Triumph Sprint GT User Manual

Specifications
121
SPECIFICATIONS
Sprint ST Sprint GT
Dimensions
Overall Length 83.2 in (2,114 mm) 88.9 in (2,260 mm)
Overall Width 29.3 in (745 mm) 37 in (940 mm)
Overall Height: 47.8 in (1,215 mm) 47.6 in (1,210 mm)
Wheelbase 57.4 in (1,457 mm) 61.6 (1,565 mm)
Seat Height 32.3 in (820 mm) 32.1 in (815 mm)
Weights
Wet Weight 531 lbs (241 kg) 590 lbs (268 kg)
Maximum Payload 473 lbs (215 kg) 473 lbs (215 kg)
Engine
Type In-line 3 cyl. In-line 3 cyl.
Displacement 64 cu in (1050 cc) 64 cu in (1050 cc)
Bore x Stroke 3.11 - 2.81 in (79 x
71.4 mm)
3.11 - 2.81 in (79 x
71.4 mm)
Compression Ratio 12.0:1 12.0:1
Cylinder Numbering Left to Right Left to Right
Cylinder Sequence Number 1 at left 1 at left
Firing Order 1-2-3 1-2-3
Starting System Electric Starter Electric Starter

Triumph Sprint GT Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement	1050 cc
Bore x Stroke	79 x 71.4 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	6-speed
Front Tyre	120/70 ZR17
Rear Tyre	180/55 ZR17
Fuel Tank Capacity	20 litres
Max Power	130 PS (95.6 kW) @ 9, 200 rpm
Max Torque	108 Nm @ 6, 300 rpm
Exhaust	Stainless steel 3 into 1
Frame	Aluminium beam
Front Suspension	43mm
Rear Suspension	Monoshock with adjustable preload and rebound damping
Front Brakes	Twin 320 mm floating discs, Nissin 4-piston calipers
Rear Brakes	Single 255mm disc, Nissin 2-piston caliper
Seat Height	815mm
Ignition	Digital inductive type
Swingarm	Single-sided, aluminium alloy
Wheelbase	1, 537 mm
