5.2.7 Exhaust segment button
The table exhaust system is divided into four independent segments.
By pressing one of the four exhaust segment buttons, the vaccum of the respective
section can be activated or deactivated. The working area which is free of material
must not be covered.
5.2.8 Max. compressed air / control lamp
Max. compressed air button: by pressing the button the maximum air pressure gets
switched on. This remains active as long as the button is pressed. The supply of the
maximum compressed air is used for example for blowing of any flame formation.
Control lamp: ON, whenever an exhaust or cooling system is not connected or not
active and therefore the interlock is not closed.
