Trotec SP3000 Operation Manual

SP3000
Maintenance
BA 8034_2.4_EN (12/2016) 71 / 87
www.troteclaser.com
1. Blow away loose particles and dust by means of a
bellows or compressed air (according to ISO 8573:2010
class 1).
2. Get the cleaning liquid and cleaning tissues ready.
3. Move the table up and put a cloth under the lens holder
(so that the lens will not be damaged if it falls out of
holder by accident).
4. Unscrew the lens fixation screw.(1 screw)
5. Carefully take out the lens. (2 screws)
6. With the aid of the supplied key tool loosen the clamping
ring by rotating it clockwise.
Key tool
