Ice Level Sensor Setup (Cont.)
Installation & Setup (cont.)
Ice level sensor presets
Full Bin Distance (FBD) Empty Bin Distance (EBD) Full Bin Ice Threshold (PBD)
Level 1 - Ice Storage Bin (Short) 30 cm 85 cm 100
Level 2 - Ice Storage Bin (Tall) 20 cm 108 cm 100
Level 3 - Countertop Dispenser 25 cm 65 cm 90
Level 4 - Hotel Dispensers 25 cm 85 cm 90
Level 5 - Custom Setup 20 cm 120 cm 60
Custom Setup
Press the values to open the number pad. Enter the desired setting and press ok.
• Full Bin Distance (FBD) is the distance in centimeters between the sensor and the ice when the machine enters the FULL BIN state
with the damper held down. See fig. 1.
• Empty Bin Distance (EBD) is the distance in centimeters between the sensor and the bottom of the ice storage unit. See fig. 1.
NOTICE ›
TRUE recommends only adjusting EBD.
