Installation & Setup (cont.)
Fig. 1. FBD vs. EBD.
FULL BIN Control
The FULL BIN state is normally controlled by the harvest flap.
However, the ice level sensor can be used to control the FULL BIN
state of the machine by setting the value of TF1 equal to 1. This is
typically used when an ice machine is installed on a dispenser and
a lower ice level is required.
The machine will enter the FULL BIN state once the Value is greater
than the Full Bin Ice Threshold [PBD].
For instance, if PBD is set to 50, then the ice machine will enter the
FULL BIN state when the Value is greater than 50% (in other words,
when the ice storage unit is at least half full).
The machine will still enter the FULL BIN state if the damper is
held down.
