43
Maintenance and Specifications
Servicing
Should your TV/VCR stop working, do not try to repair it yourself. There
are no user-serviceable parts inside the unit. Turn the TV/VCR off,
unplug the power cord, and take the unit to an authorized Trutech
repair center.
Cabinet Cleaning
To clean your TV/VCR, wipe it with a soft cloth that has been dampened
with luke-warm water and wrung dry. Never use a solvent or alcchol.
Never spray insecticides near your TV/VCR; such chemicals can cause
damage and discoloration to the exterior of your TV/VCR.
Video Head Cleaning
If the picture is blurred or interrupted when palying back a tape, it may
be caused by dirty video heads. Video heads can become dirty after long
periods of playback, or from repeated use of rental tepes. To have your
video heads cleaned, contact an authorized Trutech repair center.
Specifications
Power Supply AC 120V, 60Hz
Power Consumption 13CTT : 60W
Dimensions (WxHxD) 13CTT : 382 x 404 x 365mm
Weight 13CTT : 14Kg
Channel Coverage VHF : 2-13, CATV : 1, 14-125 ; UHF : 14-69
Video Signal System NTSC Color
Picture Tube 13” diagonal
Antenna Inpur VHF/UHF 75ohm, one input
VCR Format VHS Standard
Tape Speed SP : 33.35mm/sec ; LP : 16.67mm/sec ; EP :
11.12mm/sec
Playback Time SP : 120min ; LP:240min; EP:360min
(T-120 tape)
Speaker Output 8 Ohm, 1.3W
Video Input 1.0Vpp, 75 Ohm
Audio Input 3.8dBm, over 100K Ohm
Temperature 5˚C to 40˚C
Humidity Less than 85%
Timer Programming 6 Event / 1 Month
Tuning System Frequency Synthesized Tuning
Design and specifications are subject to changes without notice or legal obligaiton.
