TSC ME240 User Manual

29
3.1.1-1.1 Speed:
Use this option to setup print speed. Each increment/decrement is 1 ips. Printer default
density is 5 ips (203 dpi) or 3 ips(300 dpi).
Press key to raise the print speed, and press key to decrease print
speed. Press key to set it into printer. Press key to cancel the
setting and return to the previous menu.
Note: If printing from enclosed software/driver, “Use current printer settings” option
is not selected, the software/driver will send out the SPEED command, which
will overwrite the setting set from the front panel.
3.1.1-1.2 Density:
Use this option to setup printing darkness. The available setting is from 0 to 15 levels, and
the increment is 1 level. Printer default density is 8.You may need to adjust your density
based on selected media/ribbon.
Press and to increase/decrease the printing darkness. Press
key to enable the setting. Press key to cancel the setting and return to the
previous menu.
Note: If printing from enclosed software/driver, the “Use current printer settings”
option is not been used, software/driver will send out the DENSITY command,
which will overwrite the setting set from the front panel.
3.1.1-1.3 Direction:
The direction setting value is either 1 or 0. Use this option to setup the printout direction.
Printer default printout direction is DIRECTION 0.
Print Setup 1/12
>
Speed
Density
Direction
Speed
6
Print Setup 2/12
Speed
>
Density
Direction
Density
8
Print Setup 3/12
Speed
Density
>
Direction
Direction
0

TSC ME240 Specifications

General

Resolution	203 dpi / 300 dpi
Operating Temperature	5°C to 40°C (41°F to 104°F)
Print Method	Thermal Transfer & Direct Thermal
Interface	USB
Power Supply	AC 100-240V, 50/60Hz
Humidity	20% to 85% RH (non-condensing)
