26
4.5 Install Vehicle holder adapter for RAM mount (Optional)
1. Turn the printer to the rear side.
Note:
Please choose the printer with
copper pillars as indicated.
2. Install the vehicle holder adapter
align with the copper pillars and
fix with two screws as indicated.
Copper pillars
Copper pillars
