TSC TTP-244M Pro Service Manual

12
TTP-244M Pro/244ME Pro
TTP-342M Pro/342ME Pro
Bar Code Printer Service Manual
2. SUPPLY SPECIFICATIONS
2.1 Types of Paper
Three types of paper are available: (1) label, (2) ticket, (3) direct thermal
paper.
Note: Our definition of ticket is “the media with black lines on its
backing paper”.
Item (1), (2), (3) can be further classified into direct thermal type or thermal
transfer type.
2.2 Paper Specifications
Specifications
Label / Ticket
Items
Paper Width
Max. 114 mm
Min. 25.4 mm
Print Length (Pitch)
6 ~ 2286 mm (For TTP-244M Pro/TTP-244ME Pro)
6 ~ 1016 mm (For TTP-342M Pro/TTP-342ME Pro)
Thickness
0.06 mm~0.25 mm, Max 250 g/m
2
Max. Roll Diameter
Outer roll dia. 178 mm (1” core)
Roll Up Method
Print surface wound outside as standard
Paper Core ID
25.40.3 mm
Max. Print Width
25 mm (1") ~ 104 mm (4.09")
Note:
(1) The max. paper length above is for standard 8MB memory.
(2) The printing length above is based on the assumption that there is not any
downloaded file in the printer memory.
(3) The quoted width and thickness are said of the label plus the backing paper.
(4) Likewise, the approval of a label entails that of its backing paper.
(5) In the peel off mode, the minimum pitch is 35 mm.
(6) In the cutter mode, it is recommended that the print media be wound
outside lest paper jam should result.
(7) In the cutter mode, the paper thickness must be less than or equal to 250 m.
(8) Paper shape is as shown on next page:

TSC TTP-244M Pro Specifications

General

Brand	TSC
Model	TTP-244M Pro
Category	Barcode Reader
Language	English
