TSC TTP-244M Pro Service Manual

7
TTP-244M Pro/244ME Pro
TTP-342M Pro/342ME Pro
Bar Code Printer Service Manual
1.4 Basic Specifications
 Thermal transfer and direct thermal printing
 High dot density printing (203 dots/inch, 8 dots/mm; 300 dots/inch,
12 dots/mm)
 Selectable print speeds at 1.5”, 2”, 3” or 4” per second for TTP-244M
Pro/TTP-244ME Pro, and 1”, 1.5” or 2” per second for TTP-342M
Pro/TTP-342ME Pro
 Maximum media width: 4.49” (114 mm)
 Adjustable label edge guide
 International character sets
 Print area：TTP-244M Pro/TTP-244ME Pro：4.09”W x 90”L；TTP-342M
Pro/TTP-342ME Pro：4.09”W x 40”L
 User selectable bar code ratios and heights
 Printing on labels or ticket stock
 Black mark sensor
 Label stock and thermal transfer ribbon easy to load
 Internal label print counter
 Self test
 Protocol: Xon/Xoff; DSR/DTR handshaking
 Downloadable fonts from the Windows label design software
