TSC TTP-244M Pro Service Manual

22
TTP-244M Pro/244ME Pro
TTP-342M Pro/342ME Pro
Bar Code Printer Service Manual
3.4 Print Density Selection
As shown, on the lower edge of the mainboard JP47 is jumper to be used in the
selection of print density. To select 200 dpi print density, cap jumper on
positions 200DPI, as described in the instructions beside. To select 300 dpi
print density, cap jumper on positions 300DPI.
