TSC TTP-244M Pro Service Manual

5
TTP-244M Pro/244ME Pro
TTP-342M Pro/342ME Pro
Bar Code Printer Service Manual
1. Centronics interface (Option for E series)
2. USB interface
3. Label insert opening (For use with external labels)
4. RS-232C interface connector
5. SD card socket
6. Power switch
7. Power cord socket
Note: The interface picture here is for reference only. Please refer to the
specification for the interfaces availability.
* Recommended SD card specification.
SD card spec
SD card capacity
Approved SD card manufacturer
V1.0, V1.1
128 MB
SanDisk, Transcend
V1.0, V1.1
256 MB
SanDisk, Transcend, Panasonic
V1.0, V1.1
512 MB
SanDisk, Transcend, Panasonic
V1.0, V1.1
1 GB
SanDisk, Transcend, Panasonic
V2.0 SDHC CLASS 4
4 GB
V2.0 SDHC CLASS 6
4 GB
SanDisk, Transcend, Panasonic
V1.0, V1.1
microSD 128 MB
Transcend, Panasonic
1.
2.
3.
4.
5.
6.
7
