TSC TTP-247 Service Manual

7
Processor
32-bit RISC high performance processor
Memory
 4MB Flash memory
 8MB SDRAM
 SD card reader for memory expansion
Interface
 RS-232 (max. 115200 bps)
 Centronics
 USB 2.0 (Full speed mode)
Power
External universal switching power supply
 Input: AC 100-240V
 Output: DC 24V 3.75A
Operation switch, button
 One power switch
 One feed button
 One LED (3 colors green, amber, red)
Sensors
 Gap transmissive sensor (offset 6 mm from liner
edge)
 Black mark reflective sensor (position adjustable)
 Head open
 Ribbon end sensor
Internal font
 8 alpha-numeric bitmap fonts
 One Monotype Imaging® CG Triumvirate Bold
Condensed scalable font
 Build-in Monotype True Type Font Engine

TSC TTP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Max Print Width	4.09" (104 mm)
Processor	32-bit RISC CPU
Weight	2.5 kg
Max Print Speed	7 ips
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB 2.0, Serial
Ribbon Capacity	300 meters
Label Width	1" (25.4 mm) ~ 4.33" (110 mm)
Label Thickness	0.06 mm ~ 0.19 mm
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Operating Humidity	25% to 85%, non-condensing
Certifications	CE, FCC, UL, CCC
