TSC TTP-247 Service Manual

14
1.3. Supply Specification
1.3.1. Paper
Item
Specification
Type
Label (Continuous , Die-cut , Fan-fold).
Wound Type
Outside wound.
Width
20~112mm (0.78" ~ 4.4")
Length
( for peel and cutter )
10mm ~ 1000mm (0.4” ~ 39”).
25.4mm ~ 1000mm (1” ~ 39”).
Thickness
0.06mm ~ 0.19mm.
Roll Diameter
5”.
Roll Core Diameter
25.4mm ~ 76.2mm (1” ~ 3”).
Gap Height
2mm min.
Black Mark Height
2mm min.
Black Mark Width
8mm min.
1.3.2. Ribbon
Item
Specification
Type
Wax, Wax / Resin, Resin.
Core Diameter
1".
Width
Max 110mm.
Capacity
300m with 1" core.
Wound Type
Outside wound.
Ribbon End
Clear or silver end tape.

TSC TTP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Max Print Width	4.09" (104 mm)
Processor	32-bit RISC CPU
Weight	2.5 kg
Max Print Speed	7 ips
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB 2.0, Serial
Ribbon Capacity	300 meters
Label Width	1" (25.4 mm) ~ 4.33" (110 mm)
Label Thickness	0.06 mm ~ 0.19 mm
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Operating Humidity	25% to 85%, non-condensing
Certifications	CE, FCC, UL, CCC
