TSC TTP-247 Service Manual

3
1.2. Specification
1.2.1. Printer (TTP-245 Plus / TTP-343 Plus)
Item
Printer model
TTP-245 Plus
TTP-343 Plus
Resolution
203 DPI
300 DPI
Printing method
Thermal Transfer & Direct Thermal
Print speed
2, 3, 4, 5 ips.
2, 3 ips for peel model
2, 3 ips
Max. print width
108 mm (4.25”)
104 mm (4.09”)
Max. print length
2286 mm (90”)
1016 mm (40”)
Enclosure
Double-walled plastic
Physical dimension
314mm (L) x 213mm (W) x 188mm (H)
Ribbon capacity
300 meter, 1” core
Label roll capacity
5” OD
Processor
32-bit RISC high performance processor
Memory
 2MB Flash memory
 8MB DRAM
 SD card slot for memory expansion
Interface
 RS-232 (max. 115200 bps)
 Centronics
 USB 2.0 (Full speed mode)
Power
External universal switching power supply
 Input: AC 100-240V
 Output: DC 24V 3.75A
Operation switch, button
One power switch & feed button
Sensors
 Gap transmissive sensor (offset 6 mm from liner
edge)
 Black mark reflective sensor (position adjustable)
 Head open
 Ribbon end sensor

TSC TTP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Max Print Width	4.09" (104 mm)
Processor	32-bit RISC CPU
Weight	2.5 kg
Max Print Speed	7 ips
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB 2.0, Serial
Ribbon Capacity	300 meters
Label Width	1" (25.4 mm) ~ 4.33" (110 mm)
Label Thickness	0.06 mm ~ 0.19 mm
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Operating Humidity	25% to 85%, non-condensing
Certifications	CE, FCC, UL, CCC
